An interactive Typst package to easily position elements (annotations, bars, etc.) in your documents.

The Problem

Precisely positioning an annotation on an image or chart in Typst is often frustrating. You have to guess coordinates, compile, adjust, recompile…

The Solution

Coordy displays a visual marker that you can move by typing commands. Thanks to Typst’s live preview, you see the marker move in real-time and get the exact coordinates to use with place().

Installation

Once published on Typst Universe:

#import "@preview/coordy:0.1.0": ph

Usage

#import "@preview/coordy:0.1.0": ph

#show: ph("ddddzzzz")

// Your normal content
= My Title
#image("my-image.png")

The red marker overlays your content. Modify the command string to move it.

Controls (ZQSD Layout)

Key Action
z Move up
s Move down
q Move left
d Move right
a Decrease step (-1pt)
e Increase step (+1pt)
r Reset position

Parameters

Parameter Type Default Description
commands string "" Command string (zqsd…)
start-x length 297.5pt Initial X position
start-y length 421pt Initial Y position
step integer 10 Movement step (in pt)
marker-size length 8pt Marker size
marker-color color red Marker color
show-grid boolean false Display a reference grid
grid-step length 50pt Grid spacing
margin length 2.5cm Page margin (for coordinate calculation)

Workflow

  1. Add #show: ph("") at the top of your document
  2. Type commands in the string (e.g., "ddddzzzz")
  3. Watch the marker move in the preview
  4. Note the displayed X and Y coordinates
  5. Use these coordinates with place():
#place(
  top + left,
  dx: 150pt,
  dy: 80pt,
  [My annotation]
)
  1. Remove the #show: ph(...) line when you’re done

Examples

Basic

#import "@preview/coordy:0.1.0": ph

#show: ph("ddddddddddssssssssss")

= My Document
#lorem(100)

With Grid

#show: ph("dddddddddd", show-grid: true)

Custom Margins

If your document uses margins different from 2.5cm:

#set page(margin: 1cm)
#show: ph("dddddddddd", margin: 1cm)

Custom Starting Position

#show: ph("", start-x: 100pt, start-y: 100pt)

Demo

Coordy Demo

License

MIT
